House Plan Designers in Perungudi

If you're looking for House Plan Designers in Perungudi, you probably already have a plot, a rough room count in mind, and a few hard questions about approval, parking and whether the ground will take a normal footing. A good house plan is not a pretty sketch first and an engineering drawing later. It has to work on your plot, with your road width, your soil, and the way Chennai actually builds.

We prepare house plans the way they need to be built: clear room layouts, RCC structure, drainage, rainwater harvesting and the paperwork that helps the approval process move. If you want a plan for an independent house, a duplex or a compact rental building near OMR, this page will show you what matters before you spend on drawings.

Why Perungudi changes the plan

Perungudi sits in the OMR belt beside marshland and low ground in parts, so the first mistake people make is treating the plan like a pure elevation exercise. It is not. Floor level, plinth height, driveway slope, storm-water outlet and where the sump sits all need to be fixed early, because a nice-looking drawing cannot rescue a house that takes water at the gate. We see this often on plots where the owner wants the front room pushed down to gain height in the elevation; that looks neat on paper and causes trouble during the north-east monsoon.

The other local issue is access. Many plots here sit on busy internal roads with apartments and small offices around them, so material movement and shuttering space are tighter than people expect. If your plot is narrow or hemmed in, the house plan should respect the site reality from the start. In Chennai, that means planning for concrete delivery, neighbour clearances, tanker access and where labour can actually stand. If you ignore that, the construction team ends up changing the plan on site, and that is always the expensive version.

Because Perungudi is part of the Chennai Metropolitan Area, the planning side also needs to be handled properly. CMDA rules matter, and the local body that issues the building licence depends on the exact plot location and jurisdiction. We check the approval route for the plot, then shape the drawings around that route rather than forcing a generic plan into it.

What a proper house plan must settle

A house plan is more than room dimensions. For a Chennai house, it should settle structure, services and approval in one set of drawings. We start with the site sketch, road width, orientation, setback rules for that specific plot and the family’s actual use of the house. Then we build the plan around circulation, ventilation, stair position, water line, sewer line, pump room and future load if you may add a floor later.

Engineering first, drawing second

We design to Indian standards: IS 456:2000 for RCC, IS 875 for loads, IS 1893:2016 for seismic design and NBC 2016 for the building code framework. Chennai sits in Seismic Zone III, so the structure should not be treated casually even if the building is only ground plus one. Soil investigation comes before foundation design. If the log shows soft or water-retaining layers, we change the foundation approach. If the ground is firm, we may use isolated or strip footings. The cheap test is worth far less than fixing settlement later.

On a normal house plan drawing set, you should expect:

• site plan and orientation
• floor plans with furniture sense, not just room boxes
• elevation concept and section
• foundation and RCC structural drawings
• plumbing, drainage and rainwater harvesting layout
• electrical point planning and service shafts where needed
• drawing set for approval and for site execution

What goes wrong when the plan is weak

The common failures are predictable. Staircases land in awkward places. Kitchen ventilators open into a shaft that never really breathes. Car parking works only on paper because the turning radius was never checked. Owners also ask for oversized living rooms and then wonder why the bedrooms become narrow. In our experience, the second week of construction is where the real argument starts, because that's when the owner sees the brickwork lines and understands whether the plan was thought through.

1. Site visit and measurement — 1 to 2 days, including road width, boundary position and existing levels.
2. Concept plan — 3 to 5 days, with room arrangement, stair location and parking checked against your brief.
3. Approval drawing set — 5 to 7 days, with structural coordination, RWH and drainage details.
4. Revision and final issue — 2 to 4 days, after your comments and any approval-side corrections.
5. Structural design and BOQ — 4 to 7 days, so the plan and the construction cost talk to each other before work starts.

How to judge a designer before you sign

If you are comparing firms for house plan work, do not ask only for an attractive front elevation. Ask for the drawings you will get, the number of revisions, and who signs off the structural side. A proper designer should be able to explain the approval route for your plot, the likely document list, and what changes if the soil or road width is not what you assumed.

Here is the plain test we give clients: if the designer cannot explain how the plan will sit on the site, the approval body and the ground, the design is incomplete. A polished 3D image is useful. It is not enough.

• Ask for the full drawing list before you pay the advance.
• Check whether the plan has space for a sump, overhead tank and rainwater harvesting pits.
• Confirm who is doing the structural design and whether it follows IS 456:2000.
• See how the designer handles parking, stair width and future vertical expansion.
• Ask for the approval route in writing, not just in conversation.
• Make sure the BOQ comes before the contract, not after work begins.

Approvals, cost and timing

For Chennai, approvals are not guesswork. CMDA governs the planning side in the metropolitan area, while the licence comes from the body that controls that specific plot: Greater Chennai Corporation inside city limits, or the relevant municipality or town panchayat outside it. If the plot is toward airport-side areas, height clearance can also come into the picture. Patta, EC, FMB sketch, approved drawings, structural stability certificate and drainage details are the usual documents we prepare around.

Design charges themselves vary by scope, but the real cost risk is in the construction that follows the plan. Standard residential construction usually falls in the ₹1,900 to ₹2,300 per sq ft range, mid-premium runs ₹2,300 to ₹2,800, and premium work goes higher. That is only an indicative band. Soil condition, foundation type, number of floors, span, finish level and site access move the figure. A detailed BOQ settles the actual number before any contract is signed.

One honest limitation: if your plot has title issues, unclear boundaries or a pending survey problem, no plan is worth starting on top of that. Fix the paper side first. Also, if you want a purely decorative plan with no regard for drainage, future maintenance or structure, we're not the right team for that. You will get a nicer picture elsewhere, and a harder life later.

How we work on a house plan

We begin with a site visit or a measured sketch, then our in-house civil engineer, structural engineer and architect work on the same set. Nothing is outsourced. Mr. D. Salamon Ashok Rajan reviews the technical side, and a site engineer stays involved every working day once construction starts. If you cannot visit often, we send weekly photo updates by WhatsApp. That is usually what busy owners ask for first, right after they ask whether the stair can be shifted or the car porch widened.

If you want us to look at your plot in Perungudi, call +91 97107 13838 or write to info@shalomconstruction.com. Our office is at No. 45, 2nd Main Road, Abirami Nagar, Koladi, Thiruverkadu, Chennai – 600077, and we also answer on +91 99941 32004.

Frequently Asked Questions

If you want a house plan that suits your plot, not just a software drawing, we can help. We work across Chennai, and Perungudi needs the same thing every other serious site does: ground sense, clean drawings and a plan the contractor can actually build.
