Building Elevation Designers in Kundrathur

If you are comparing building elevation designers in Kundrathur, you're probably past the first sketch and already wondering what the front of the house will cost, how it will look from the road, and whether the drawing will still work when the engineer checks the structure. That is the right stage to slow down a little.

Elevation is not just a pretty front image. On a Kundrathur plot, it has to sit with the road level, the plot width, the neighbour walls, the stair position, the beam layout and the approvals. We design it so the front looks like a house, not a pasted-on façade.

What changes on a Kundrathur plot

Kundrathur sits outside the Corporation side of Chennai, so the licence route is usually through the local municipality or town panchayat side depending on the exact survey location, while CMDA rules still shape the planning work in the metropolitan area. That means the drawing set has to be practical, not theatrical. People here often build on regular residential plots, some with tight frontage and some with enough width for a clearer front composition, but the road edge, gate line and rainwater entry point still decide the first impression.

The other thing people miss is access. In a developed layout, you may have enough space for shuttering material, a small mixer, and safe movement of steel. In a narrower street, the front elevation has to respect what can actually be built without blocking the lane for neighbours. The best-looking design on paper can become a nuisance if it ignores site logistics.

In this part of the city, many owners also want a front that looks premium without pushing the budget into decorative overload. That is sensible. A clean massing with the right window spacing and a clear parapet line usually ages better than a crowded front with too many projections. We have seen too many houses in west Chennai where the elevation looked busy on day one and tired by year three.

How we design the front

We start with the structure, not with cladding. The beam positions, stair block, terrace access and floor-to-floor heights are fixed first, then the elevation is built around them. That is the only way the drawing stays honest. IS 456:2000, IS 875, IS 1893:2016 and NBC 2016 guide the engineering side, while the architecture has to remain workable for the plot and the way you want to live.

What the drawing set usually includes

For a proper house front, you should not settle for a single perspective image. You need the front elevation, side treatment if the side is visible, section references, opening positions, parapet design, balcony projection where it is actually feasible, and the finish schedule. If the front has a compound wall, gate and name board, those should be thought through at the same time. A house reads as one composition.

We also check sunlight and rain. A projection that looks good in a render may collect water where two finishes meet. A deep recess can become a dirt trap. In our experience, the second monsoon is where weak elevation details show up: stains under chajjas, hairline cracks around ornament strips, and water marks on unprotected exterior paint.

1. Plot study and measurement — 1 to 2 days on site for the actual dimensions, road edge, setbacks available on the specific plot and any neighbour constraints.
2. Concept elevation — 3 to 5 days for front massing, window rhythm, stair placement and two or three practical looks that suit the house type.
3. Structural coordination — 2 to 4 days to align the elevation with beams, columns, slab edges and terrace access so nothing is forced later.
4. Revision and final drawing — 2 to 3 days for client comments, material notes and the final set used for execution.

What people usually ask for first

Most owners do not begin with a technical brief. They come with one of three things: a photo of a front they liked, a rough budget in mind, or a concern that the house will look too plain from the road. All three are valid starting points, but none of them should decide the final drawing by themselves.

• A front that looks neat from street level, not only in a rendered image.
• A design that can be built with ordinary Chennai materials and labour.
• Window sizes and balcony lines that match the inside rooms.
• External finishes that do not demand high maintenance every few months.
• A parapet and terrace edge that will not collect water or crack early.
• Enough detail to estimate cost before you commit to the structure.

That last point matters more than people expect. An elevation is not free decoration added at the end. It changes shuttering, finishes, aluminium work, exterior paint and sometimes even the way a porch or stair block is formed. If the front is decided after the structural work has started, the bill usually goes up and the house becomes harder to balance visually.

Cost, finish level and what drives it

If you are asking about rate, an elevation drawing itself is part of the architectural work, while the actual exterior cost depends on the finish you choose. For residential construction in Chennai, standard finishes generally fall around ₹1,900 to ₹2,300 per sq ft, mid-premium around ₹2,300 to ₹2,800 per sq ft, and premium or luxury above that. Those figures move with soil and foundation type, number of floors, span, finish level and site access. The BOQ settles the real figure before any contract is signed.

For elevation work, the cost drivers are usually simple. A straight, clean façade with paint and modest grooves is cheaper than a front loaded with cladding, boxes, hidden lighting, pergolas and custom railings. That does not mean the cheaper option is always better. It means the money should go where the house will actually age well: waterproofing at exposed junctions, good plastering, proper exterior paint, and detailing around windows and sunshades.

Saving on the wrong part is common. People try to reduce exterior cover details, terrace edges or paint quality, then spend more later fixing stains and cracks. Saving on ornaments is often wise. Saving on waterproofing is not.

How we approach the work

We keep the design and structural work in-house, so the elevation is not handed around between separate people who do not share the same site notes. A site engineer is on site every working day, and our clients get weekly WhatsApp photo updates if they cannot visit. Mr. D. Salamon Ashok Rajan, our managing director and civil engineer, personally reviews projects, which helps when a front design needs a practical call instead of a decorative one.

If you want to talk through a Kundrathur house front, we can look at the plot, the room plan and the budget together, then prepare a BOQ-based direction instead of guessing. You can call us on +91 97107 13838 or write to info@shalomconstruction.com. Our office is at No. 45, 2nd Main Road, Abirami Nagar, Koladi, Thiruverkadu, Chennai – 600077, near Ratna Chamber.

Frequently Asked Questions

Good elevation work is quiet when it is done right. The front just fits the street, the windows look like they belong there, and the house still makes sense after a few monsoons. That is the standard we use.
