When you’re planning a new house in Iyyappanthangal, the front elevation is usually the first thing your family argues about and the last thing the local body asks for. Good building elevation designers in Iyyappanthangal should solve both: how the home will look from the road, and how the drawings will hold up when you start approval, structure and execution.
We design elevations for Chennai plots with real site constraints in mind, not just a pretty façade. That means road width, neighbour offsets, rain splash, sun on the west side, compound wall height and the actual wall line all get looked at before anyone starts sketching arches or cladding.
What changes on an Iyyappanthangal plot
Iyyappanthangal is on the western side of Chennai, where you see a mix of independent houses, new layouts and apartment blocks around the Poonamallee road belt. The roads are broader than the old city in many pockets, but the plot shapes are not always simple, and that affects the elevation more than people expect. If your frontage is narrow, a busy elevation with too many projections can make the house look cramped. If your plot is deeper, you can push the massing back and keep the face cleaner.
This part of the city also sees hot afternoon sun on the west and south-west side. That matters. A glass-heavy front wall looks good in a rendering, but it can heat up the living room and make the interior finish work harder. In our experience, people who call us from this side of Chennai usually want a modern front, but they also want less maintenance, because dust from traffic and monsoon spray both show up quickly on a badly detailed façade.
Approval is another reason elevation work cannot be treated as decoration. The building licence route depends on the exact plot location, and CMDA rules sit behind the local body process. We keep the elevation in sync with structural lines, stair headroom, terrace needs, rainwater harvesting and the drawings that will actually be submitted. A nice sketch that cannot be built is a waste of your time.
How we shape the front of the house
For a house elevation, we start with the actual building volume and the way the family uses the house. A duplex with a sit-out and car porch needs a different front rhythm from a compact G+1 rental house. We look at window placement, balcony depth, staircase position, parapet height, sunshade lines and where rainwater will fall during the monsoon. That is where the design becomes practical.
What the drawing set should contain
A proper elevation design is not just one colored image. You should get front, side and rear views where needed, with floor-to-floor levels understood, material calls where necessary, and a plan that ties into the structural drawing set. If we are designing for RCC construction, the elevation must respect beam positions, slab edges and column lines under IS 456:2000, with load assumptions in line with IS 875 and seismic detailing under IS 1893:2016 for Chennai’s Zone III conditions.
We also check where the exterior finish will fail first. Joints around windows, the top of compound walls, horizontal ledges and recessed frames all need care. If they are drawn too boldly, they collect water and stains. If they are drawn too plain, the house can look flat and unfinished. That trade-off is where real design work happens.
- Site reading — We check the plot dimensions, road side, opening side, nearby buildings and likely sun exposure. This usually takes the first meeting and a site visit.
- Concept elevation — We sketch the massing, window balance and front profile. For most homes, this is where the first round of changes happens.
- Drawings tied to structure — The elevation is aligned with columns, beams, stair core and terrace level so there are no surprises later.
- Material and finish selection — We fix where paint, texture, tile cladding, MS features or stone will actually be used and what maintenance each one will need.
- Final issue for approval and execution — The drawings are checked with the rest of the building set, so the contractor is not left guessing on site.
How to judge a designer before you sign
If you are comparing firms, don’t ask only for pretty images. Ask what happens if the structure changes by a few inches, how many revision rounds are included, and whether the elevation has been checked against the plan and section. Ask to see a BOQ or at least a clear drawing scope. If someone is vague about what you receive, the project usually gets vague later too.
- Ask for front, side and where needed rear views, not just one rendered image.
- Check whether the design is tied to the actual floor plan and column layout.
- Ask how many revision rounds are included before the final issue.
- See whether rainwater detailing and exterior maintenance are part of the discussion.
- Confirm who will coordinate the elevation with structure and approval drawings.
- Reject any answer that says, “We’ll fix it on site.” That sentence costs money later.
Cost, approvals and what drives the work
Elevation design fees are usually a small part of the overall project, but the choices made here affect wall thickness, finish material, labour time and maintenance for years. If you want a budget-conscious house, the smart move is to keep the massing simple and spend only where the front truly needs character. If you want a premium face, use fewer materials well instead of piling on bands, grooves and cladding that age badly.
For the construction itself, standard residential work in Chennai usually falls in the ₹1,900 – ₹2,300 per sq ft range, mid-premium work in the ₹2,300 – ₹2,800 band, and premium homes above that. Those numbers move with soil and foundation type, number of floors, span, finish level and site access. The detailed BOQ settles the real figure before any contract is signed. We do not quote a total project price from a page like this, because no responsible engineer should.
| Design choice | What it changes | What usually goes wrong |
|---|---|---|
| Simple box form | Lower build cost, easier waterproofing, cleaner execution | Can look plain if window proportions are ignored |
| Projection and recess | Creates depth and shadow on the front | More joints and more places for seepage if detail is poor |
| Cladding or texture finish | Visual strength and a more premium look | Extra dead load, dust pockets, and patch repairs later |
| MS pergola or feature frame | Strong street presence | Corrosion, paint failure and heat gain if it is not detailed well |
How we work on elevation drawings
We keep the technical work in-house. Our civil engineers, structural engineer and architect work together, and a site engineer is on site every working day once construction starts. If you cannot visit often, we send weekly photo updates by WhatsApp. Before any contract is signed, you get a detailed BOQ and a milestone-linked payment schedule. That keeps the drawing stage and the site stage from drifting apart.
If you want us to look at your plot in Iyyappanthangal, we can start with the plan, the road side and the front look you have in mind. You can reach us at +91 97107 13838 or write to info@shalomconstruction.com. Our office is at No. 45, 2nd Main Road, Abirami Nagar, Koladi (Landmark: Ratna Chamber), Thiruverkadu, Chennai – 600077.
Frequently Asked Questions
Some homes need a simple, calm front. Others need a sharper street presence because the plot sits on a wider road or the family wants a more contemporary look. The right answer is the one that fits your plot and your maintenance tolerance, not the loudest drawing.
