Architectural Design Services in Navalur

If you’re planning a house, villa, or apartment building in Navalur, the drawings have to do more than look good on screen. They must fit the plot, the road, the parking, the plumbing runs, and the approval route before a single brick is ordered.

We handle architectural design with the building in mind, not just the elevation. That means usable room sizes, a clean structural grid, practical stair placement, and drawings that can actually move through CMDA-related checks and local licence procedures.

What changes on a Navalur plot

Navalur sits on the growth corridor where villas, apartments, and compact independent houses all compete for the same land. The first thing we look at is not the elevation sketch; it is access, plot shape, side setbacks that will be checked for that specific site, and how the building will sit against the road and neighbouring walls. Some plots are easy to lay out. Others look generous on paper and then lose half their value to turning space, stair location, septic or sewer routing, and the fact that the compound wall is too close to the entry.

The local practical issue is not drama, it is fit. In this part of Chennai, many owners want a compact villa with a car park, a pooja room, one guest bedroom downstairs, and three bedrooms upstairs, all inside a plot that leaves little room for waste space. If the plan is drawn like a showroom, you end up with narrow passages, awkward toilet positions, and windows that face walls. We see that mistake often on fast-moving suburban sites. The repair is to start with the actual plot lines, the road width, and the way you live.

How we shape the design

Architectural design here has to work with Indian standards from the first sketch. The structure is coordinated with IS 456:2000 for RCC work, IS 1893:2016 for seismic design, IS 875 for loads, and NBC 2016 for the parts of the building that affect safety and use. In Chennai we also keep rainwater harvesting in mind from day one, because it is not a decorative add-on. It affects terrace levels, drain routing, recharge points, and where services can pass without conflict.

We prepare the drawings in layers. First comes the space planning. Then the column grid and stair position. Then the service lines, because a good plan is one where the kitchen, toilets, shafts, and shafts-to-roof routing are decided before finishes. Finally, we align the drawings with the soil report and the foundation decision. If the test shows soft layers, we change the foundation strategy. If the ground is firm, isolated footings or strip footings may be the sensible answer. The test costs far less than a wrong foundation.

What clients usually ask us to fix

Most owners don’t ask for “architecture” in the abstract. They ask for better light, one extra usable bedroom, a stair that doesn’t waste half the front, or a front elevation that looks current without becoming expensive to build and maintain. In Navalur, the other repeat question is about parking. If the car cannot enter, turn, and leave without a ten-point manoeuvre, the plan is wrong. We’d rather lose a fancy corner wall than force bad parking into a plan.

1. Plot study and brief — We study the site dimensions, road side, access, and your room list, then freeze the brief in the first meeting. This usually takes 2 to 4 days.
2. Space plan — We place rooms, stairs, parking, and service shafts. This is where most design mistakes are either caught or allowed to grow. Allow 1 to 2 weeks.
3. Concept elevation — We prepare the front and side massing, check proportions, and keep the elevation tied to the real structure, not a floating skin. Usually 1 week.
4. Coordinated drawings — Architectural, structural, and service coordination happen together, then the set is issued for approval and construction use. Expect 1 to 3 weeks depending on revisions and plot complexity.

What you should verify before you appoint anyone

If you are comparing firms for architectural design services in Navalur, ask for the drawings before you talk about finishes. A pretty elevation means little if the stair is cramped, the parking space is unusable, or the plan cannot be approved. A good firm should be able to explain what is included, what is not, and where the limits are.

• Ask for a room-by-room drawing list, not a vague promise of “complete design”.
• Check whether the set includes plans, elevations, sections, and basic service coordination.
• Ask how many revision rounds are included before the drawings are frozen.
• Confirm who handles coordination with structural design and site measurements.
• See a BOQ before contract signing if the work will move into construction.
• Ask how the plan deals with parking, rainwater harvesting, and terrace drainage.

Approvals, deliverables and practical timing

For a plot in the Chennai Metropolitan Area, the planning authority is CMDA. The licence-issuing body depends on where the plot sits, so the process may run through Greater Chennai Corporation, a municipality, a town panchayat, or a cantonment board in a special case like Pallavaram. Near the airport side, height clearance can also become relevant. We do not guess those items. We check the plot details first, then prepare the drawings and documents that the authority will actually look for.

The usual document set includes patta, encumbrance certificate, FMB sketch, approved architectural drawings, structural stability certificate, and drainage details. For an owner, the practical point is simple: design and approval are not separate worlds. If the plan is drawn without checking the approval route, you end up revising it later, and revisions cost time. In our experience, that delay hurts more than the drawing fee ever did.

How we work on design jobs

We keep the work in-house with civil engineers, a structural engineer, and an architect. Mr. D. Salamon Ashok Rajan personally reviews projects. A site engineer is on the job every working day once the project moves forward, and clients who cannot visit get weekly photo updates by WhatsApp. We also issue a detailed BOQ before any contract is signed, because drawings without quantities lead to arguments later.

If you want to discuss a new house, a villa layout, or the design side of a renovation, call us on +91 97107 13838 or write to info@shalomconstruction.com. Our office is at No. 45, 2nd Main Road, Abirami Nagar, Koladi (Landmark: Ratna Chamber), Thiruverkadu, Chennai – 600077.

Frequently Asked Questions

Good design saves arguments later. It also makes the site easier to build, which is the part people rarely see until the labour starts and the first concrete truck arrives. If you want drawings that fit the plot in front of you, not a template copied from somewhere else, we can help.
