Architects in Velachery

If you are looking for architects in Velachery, you are probably trying to fit a house, villa or rebuild plan into a tight plot, a flooded street edge, or a family budget that cannot keep stretching. The drawing has to work on paper, but it also has to work when the mason is standing there and the lorry is blocking the lane.

We design with that reality in mind. That means clear drawings, proper structural coordination, and approvals that match the actual plot conditions, not a pretty plan that falls apart once you start digging.

Why Velachery needs a different design approach

Velachery is not a place where you can treat the site like a blank sheet. Parts of it sit low, the ground can hold water after heavy rain, and many streets are already built tight on both sides. That changes the first drawing itself. Plinth level, rainwater path, site access, sump location and where the septic or sewer line will run are not afterthoughts here; they are decisions that affect the whole house.

We also see a lot of rebuilding and first-time house construction on narrow plots. In such sites, the stair position, column layout and parking turning space matter more than a fancy front elevation. If the plan does not respect the plot shape, you end up wasting area in passages and odd corners. Then clients start cutting things later, and that is where trouble begins.

Another local fact is approval discipline. Velachery sits within the Chennai metropolitan system, so the planning side is not casual. The exact authority and drawings depend on the plot location and building type, and the approval path must be checked before work begins. A decent design office will tell you that straightaway rather than promising a quick sketch and sorting the rest later.

What we design and coordinate

As architects, we do more than draw a front view. A usable house plan starts with the family pattern, the plot dimensions, the road width, the car movement and the way light enters the rooms. After that comes the structural grid, because the beam and column positions must support the plan without forcing ugly compromises later. In Chennai, we design to IS 456:2000 for RCC, IS 1893:2016 for seismic design, IS 875 for loads, and NBC 2016 for general building requirements.

The drawings that actually matter

You should not pay for a bundle of sheets that look impressive and do not help the site engineer. The set should be useful. That means the concept plan, dimensioned floor plans, elevation, sections, door and window schedule, basic sanitary layout, and the structural coordination set. For a normal house, we also keep the rainwater harvesting arrangement in view from the start, because Tamil Nadu has made it mandatory and it affects terrace and site plumbing layout.

Soil investigation comes before foundation design. We do not guess the footing type from the locality name. If the soil report shows soft or water-retaining layers, the foundation decision can change to raft or pile with tie beams. If it shows firm strata, isolated or strip footing may be enough. The test is cheap when compared with repair work later.

1. Site study — plot check, road access, levels, setbacks, neighbour constraints and utility points; usually 1 to 2 site visits.
2. Concept planning — room arrangement, parking, stair position and elevation direction; 3 to 7 days for the first draft.
3. Structural coordination — column grid, beam lines, slab spans and service openings; done before finalising the plan.
4. Approval drawings — sets prepared for the local licence route, with documents such as patta, EC, FMB sketch and drainage details as needed.
5. Execution drawings — working drawings for site use, so the contractor does not improvise critical dimensions on the day.

How to verify an architect before you sign

People often ask us how to choose safely. The answer is simple: ask to see the drawings, the document list and the contract structure before you discuss colour or elevation style. A serious architect will talk about measurement, approvals, structural coordination and revisions. A weak one will stay on 3D views and mood boards.

Do not accept a vague promise like “we handle everything” unless it is written down. Ask who is preparing the structural drawings, who checks the soil report, how many revision rounds are included, and what happens if the approval authority asks for changes. You need clear ownership of each stage. Otherwise, the architect, engineer and contractor spend time pointing at each other.

• Ask for a drawing list, not just a concept image.
• Check whether the structural work is in-house or passed around.
• See the revision count in writing before payment.
• Confirm who handles approval drawings and follow-up with the local body.
• Look for a proper BOQ if construction is part of the scope.
• Reject a plan that ignores drainage, rainwater harvesting or terrace maintenance access.

Approvals, documents and timelines

For a plot in Chennai, the approval route depends on where the site sits. Inside city limits, the building licence route is with Greater Chennai Corporation. Outside that, it may fall under a municipality or town panchayat such as Thiruverkadu, Poonamallee, Tambaram or similar local bodies. CMDA planning control still matters in the metropolitan area. Near the airport side, AAI height clearance can also come into play. The exact path is plot-specific, so it should be checked before the design is frozen.

The documents commonly asked for are patta, encumbrance certificate, FMB sketch, approved architectural drawings, structural stability certificate and drainage details. Some plots move quickly because the papers are clean and the road width is regular. Others take longer because a neighbour wall, access issue or old subdivision sketch needs correction. No honest office can promise the same timeline for both.

What we do on site

We keep an in-house civil engineer, structural engineer and architect in the loop, because design and execution break down when they are treated as separate worlds. A site engineer is on site every working day. If you cannot visit often, we send weekly photo updates by WhatsApp, and the contract follows a milestone-linked payment schedule. Before signing, we prepare a detailed BOQ so the cost is tied to actual quantities and specifications, not guesswork.

Most clients want one thing from the architect: fewer surprises. That is fair. In our experience, the second week on a Chennai site tells you a lot. If the levels are wrong, the rainwater path is wrong, or the column positions were made up after the plan was fixed, the mistakes show up quickly. We try to stop that before the first pour.

If you want to discuss a Velachery plot, call us at +91 97107 13838 or write to info@shalomconstruction.com. If you also need construction, our residential and renovation pages will help you see how the design translates into work on site.

Frequently Asked Questions

If your plot is ready and your papers are in hand, we can help you move from idea to a drawing set that a site team can actually use. If the site is still uncertain, we can still start with the facts and avoid mistakes that are expensive to undo.
