House Plan Designers in Kundrathur
If you are searching for house plan designers in Kundrathur, you probably already have a plot, a budget in mind, and one worry: will the drawing suit the land, the road width, and the approval route, or will it only look good on paper?
We design house plans that a real site can carry. That means room layout, ventilation, staircase position, structural grid, rainwater harvesting, and the paperwork that comes after, not before. In Kundrathur, that order matters.
What changes on a Kundrathur plot
Kundrathur sits on Chennai’s western side, outside the Corporation limits, where layouts keep changing and plots are often larger than the older city. That sounds simple until you start placing rooms. Many plots here have different frontage-to-depth proportions, some streets are still narrow, and the authority that issues the building licence is not the same as the planning authority. CMDA planning controls still matter, but the licence route depends on whether the plot falls under the municipality or a town panchayat jurisdiction, so the drawing set has to be matched to the specific site.
The ground side also affects the plan. In this part of the city, you are more likely to meet firmer ground than the low marshy belts to the south, but we never assume a footing type from locality alone. We ask for a soil test, then decide whether isolated footings, strip footings, raft, or a tied foundation system makes sense. That decision changes the plan too, because column positions, stair placement and even room spans are easier to fix before the structural drawing is frozen.
One more local reality: many Kundrathur plots are bought for an independent house with ground plus one floor, sometimes with provision for a future second floor. You should plan for that on day one. If you don’t, the staircase ends up awkward, the column grid gets forced, and the first floor feels like an afterthought.
What the plan has to solve
A good house plan is not a pretty floor arrangement. It is the answer to a dozen awkward questions. Where does the morning sun enter? Can the kitchen vent without smelling the stair hall? Is there enough setback left for service access, drainage and a small sump room? Can a concrete lorry or pump vehicle reach the plot without blocking the whole street? In Kundrathur, those questions are real because many sites sit on active residential streets, not open campus-style layouts.
Design that suits how families actually live
Most homeowners who call us for plan work are not asking for a “luxury elevation” first. They ask where the pooja room should go, whether the parent bedroom can stay on the ground floor, and how to keep the kitchen away from the front door. Those are practical questions. We start with them, then fit the structural grid around the answer. A plan that forces you to walk across the dining area to reach the master bedroom gets annoying within a month.
We also keep the service shafts, tank locations and toilet stack positions sensible. If toilets are scattered without thought, plumbing becomes longer, falls become harder to maintain, and future leakage repair is a mess. A house plan should make the building easier to construct and easier to live in. If it only looks balanced in a printed brochure, it has not done its job.
- Site study and measurements — we check the plot dimensions, approach road, orientation, adjacent buildings and access for material. This usually takes one visit and the first round of clarification.
- Space planning — we place the rooms, stair, kitchen, toilets and parking in a workable layout. You see the first scheme before anything is detailed.
- Structural coordination — our structural engineer and architect coordinate column positions, slab spans and staircase geometry, so the plan can actually be built without waste.
- Approval drawing set — we prepare the required architectural drawings, structural inputs and supporting details for the licence route applicable to the plot.
- Final revisions and BOQ — we close the drawing set, issue the detailed BOQ, and only then move to contract and execution.
How to judge a plan designer
If you are comparing house plan designers in Kundrathur, don’t start with the elevation image. Ask for the drawing list. A serious team should be willing to show you the site plan, floor plans, elevation, section, structural coordination notes, and the service details that support the building. If they cannot explain how the staircase headroom is handled or where rainwater is collected, they are selling a picture.
- Ask whether the plan is made after measuring the plot, not from a rough sketch sent on WhatsApp.
- Ask who coordinates the structural drawing with the architectural plan.
- Ask how many revision rounds are included before the final drawing is issued.
- Ask whether the design considers CMDA-related documents, rainwater harvesting and the local licence route.
- Ask for a BOQ before you sign any agreement.
- Ask what changes if you want a future second floor later.
A fair contract should say what drawings you receive, what revisions are included, when payment is due, and what counts as an extra. It should not hide behind vague phrases like “complete design solution.” You need to know whether the price includes architectural drawings only, or structural design, approval support and interior coordination too. Those are different scopes, and confusion here is where most disputes start.
Drawings and details you should receive
For a normal independent house, the drawing package should make the construction team’s job possible without guesswork. That means the plan, dimensions, openings, section cuts, stair details, toilet locations, terrace treatment, rainwater harvesting provisions, and structural coordination. Where the design needs it, we also prepare the service routes for plumbing and electrical so walls are not hacked open later.
We work to Indian standards, not guesswork. For RCC structures we follow IS 456:2000, structural load checks are guided by IS 875, seismic detailing is aligned with IS 1893:2016, and the overall house design needs to sit comfortably within NBC 2016. Chennai falls in Seismic Zone III, so the structure must be regular enough to behave properly. A random column shift to save a little space can create a much bigger problem later.
| Item | What it should cover | Why it matters |
|---|---|---|
| Site plan | Plot dimensions, road access, orientation, setbacks as applicable | Fixes the building on the ground and avoids later approval trouble |
| Floor plan | Room sizes, stair, passages, toilets, kitchen, parking | Decides daily use and construction efficiency |
| Structural coordination | Column positions, slab spans, beam alignment, foundation logic | Prevents awkward changes during execution |
| Service details | Plumbing, rainwater harvesting, drainage, electrical routes | Reduces rework and leakage-prone patches later |
| Revision control | Clear rounds of changes before final issue | Keeps the drawing from drifting during discussion |
Approval, rate and timeline
The plan itself is one part. The licence route is the next. For plots in this belt, the papers often include patta, encumbrance certificate, FMB sketch, architectural drawings, structural stability certificate and drainage details. The exact body issuing the building licence depends on the plot location, and near airport-facing belts an AAI height clearance can also come into play. We do not guess that part from a pin on a map; we verify it for your plot.
Design fees vary by scope, but actual construction rates in Chennai are still tied to the table we use across the company. For standard residential construction, the indicative rate is ₹1,900 to ₹2,300 per sq ft, mid-premium is ₹2,300 to ₹2,800, and premium homes go higher. Those figures move with soil, foundation type, number of floors, finish level and site access. The BOQ settles the real figure before any contract is signed.
If you want a practical timeline, a simple independent-house plan can move from site study to final drawing in a few weeks if your decisions are clear. The more versions you ask for, the longer it takes. That is normal. A good designer will not rush the drawing just to keep the file moving.
How we work here
We handle plan design with our in-house civil engineers, structural engineer and architect. A site engineer is on site every working day once execution starts, and clients who cannot visit get weekly photo updates by WhatsApp. Mr. D. Salamon Ashok Rajan personally reviews the project direction. We also prepare the detailed BOQ before any contract is signed, so you know what the plan means in money terms before work begins. If you want to discuss a new house in Kundrathur, call +91 97107 13838 or write to info@shalomconstruction.com, and we will tell you what the site needs before we talk about finishes.
Frequently Asked Questions
If you want a plan that fits the plot instead of fighting it, start with the ground facts and the approval route. That saves more money than any fancy elevation trick.
House Plan Designers in Kundrathur
Send us your plot details or call for a site visit. We will tell you what can be built, what needs checking, and what should wait until the soil and approval facts are clear.
