3D Elevation Designers in Vandalur

If you are planning a new house in Vandalur, 3D elevation designers in Vandalur should help you see the front of the building before one brick is laid. That matters here because many plots are still part of fast-changing layouts, and the road, compound wall, gate and staircase all affect how the house will finally look.

We design elevations to suit the plot, the road width, the likely finish budget and the way Chennai heat and rain actually behave on a wall. The result should not be a fancy picture that looks different once the structure comes up. It should be a drawing you can build from, price from and approve with confidence.

What changes in Vandalur

Vandalur sits on the southern growth belt, near layouts that are still forming and plots that vary a lot in frontage and depth. That changes the elevation problem. On a narrow frontage, the front wall, balcony projection and stair headroom need to be planned together. On a wider plot, the question is different: how to keep the elevation clean without spending on cladding that ages badly in heat and dust.

The other local point is approvals. A plot in this belt may fall under a municipality or town panchayat rather than the Corporation, while CMDA rules still matter in the Chennai Metropolitan Area. If the site is closer to the airport side, height clearance can also come up. We do not guess those items from memory. We check the plot papers, road details and the local body route first, because a neat elevation on paper is useless if the drawings do not match the approval path.

Most owners here ask for a house that looks modern but still stays practical for family use. That usually means shade, simple massing, fewer awkward projections and materials that can be cleaned without special treatment. A design that looks good only in a rendered image is the wrong answer.

How the elevation is actually designed

We begin with the floor plan, the road side, the sun path and the height the structure can truly take on that plot. Then we place the staircase, balcony lines, sunshade depth, parapet shape, gate rhythm and compound wall together. A good front elevation is not drawn separately from the building. It is built from the building.

For Chennai homes, IS 456:2000, IS 875, NBC 2016 and IS 1893:2016 guide the structural side, while the aesthetic side has to work with real weather. In a place like Vandalur, dust and rain streaking are normal. Deep grooves, overcomplicated ledges and decorative bits that trap dirt look good for a few months and then start to age badly. That is why we prefer elevations that can be painted and maintained by a regular homeowner, not only by a photographer.

What the drawing set should include

A proper elevation package is more than a front picture. You should receive the front, side and where needed rear views, floor-to-floor height references, parapet and terrace edge treatment, staircase visibility, material notes and the colour palette. If the design uses tiles, stone, texture paint or aluminium features, that should be marked clearly so the contractor does not improvise on site.

1. Plot study — we review the survey, road side, facing, setbacks decided for that plot and the usable frontage before drawing.
2. Massing concept — we sketch the building form, stair block, balcony position and the main visual balance, usually in a few working days.
3. 3D views — we prepare the elevation views so you can judge proportions, openings and material mix before finalising.
4. Revisions — we adjust the design after your comments, usually for real points like window size, gate style or colour tone.
5. Issue for execution — we freeze the approved elevation with notes that the site engineer can follow during construction.

Choosing the right front design

Most people think the main choice is between "simple" and "premium". That is not the real decision. The real choice is between a front that will stay clean in Chennai weather and one that will need constant repainting or patch repairs. A boxy design with fewer joints may look plain on a brochure, but it often performs better than a heavily cut-up façade with many water traps.

There is also a trade-off on materials. ACP, HPL, stone cladding, textures, glass railings and metal fins all have their place, but they do not suit every house or budget. Stone can age well if detailed properly, but it adds dead load and needs careful fixing. Glass looks light, but it demands maintenance and a clear idea about privacy. Texture paint is economical, yet it needs good base preparation or it will crack and stain. We tell you where each option helps and where it becomes expensive without adding value.

• Check whether the front design can be built with the actual floor height on your plan.
• Ask if the balcony and sunshade details shed rainwater away from the wall.
• Confirm what finish is on the drawing, not just what appears in the rendered image.
• See whether the design still works if you reduce one expensive material.
• Make sure the staircase, compound wall and gate line are shown together.
• Reject any elevation that hides the terrace drain or ignores maintenance access.

Approvals, timelines and design cost

For a new house, the elevation cannot be separated from the approval set. The municipality, town panchayat or Corporation route decides where the drawings go, while CMDA and other local requirements shape the file. We also check if the plot needs soil investigation before foundation design. That is not overkill. It is cheaper to test the ground than to discover later that the foundation choice was wrong.

Design work is usually quicker than construction, but it still needs a proper sequence. A simple elevation may be completed in a short design cycle, while a more detailed front with multiple material options takes longer because each revision affects the structural and service coordination. If the owner wants a front wall, roofline, gate and compound style that all match, we need time to make the proportions work.

If you are comparing design fees with construction rates, keep the two separate. The construction rate for a standard residential project in Chennai is usually ₹1,900 to ₹2,300 per sq ft, mid-premium is ₹2,300 to ₹2,800 per sq ft, and premium can go higher. Those rates change with soil, foundation type, floor count, span, finish level and site access. The BOQ settles the real figure before any contract is signed.

How we work

Our in-house architect, civil engineers and structural engineer handle the design together, so the elevation does not get disconnected from the structure. A site engineer is on site every working day once the project starts. We also share weekly photo updates on WhatsApp for clients who cannot visit the plot often. If you want us to look at your Vandalur site, call +91 97107 13838 or write to info@shalomconstruction.com. We can also meet you from our office at No. 45, 2nd Main Road, Abirami Nagar, Koladi, Thiruverkadu, Chennai – 600077.

Frequently Asked Questions

If you want the front of your house to look right on paper and still make sense on site, we can help with that. Send us the plot details and we will tell you what the design can carry and what it cannot.
