3D Elevation Designers in Porur

If you're planning a house in Porur, the front view matters earlier than most people expect. A 3D elevation drawing helps you see the roofline, window rhythm, compound wall, balcony projection and colour balance before masonry starts.

That matters in Porur because many plots sit on busy streets or near tight junctions, and the first thing people notice from the road is the front face. We design elevation drawings that make sense for the structure, the budget and the approval process, not just for a screenshot.

What Porur changes on the drawing board

Porur is not a place where you sketch a pretty front and ignore the site. The area has a mix of apartments, independent houses, commercial stretches on Mount-Poonamallee Road and plots where the access road is not generous. That means we have to think about how the elevation reads from a moving vehicle, how much balcony depth your structure can actually carry, and how the compound wall and gate sit with the road level.

The other local issue is water and finishing. Near the lake influence and the low pockets around the wider Porur belt, exterior detailing has to respect drainage and splash zones. A clean line on paper can become a stained wall if sill levels, rainwater pipes and coping are treated casually. We look at all of that before we model the front.

In Chennai, approval and construction logic also sit together. The architect, structural engineer and civil team should be talking to each other from the first week, because the elevation is not separate from the RCC frame. If a client wants a heavy frame projection, a floating staircase look or a deep sunshade, the structure has to be designed for it.

The structure behind a good elevation

A workable 3D elevation is not just a render. It starts with the floor plan, then the structural grid, then the section heights, and only then the finishes. We build the front view around actual beam positions, slab levels, staircase rise and service routes. That is why our in-house architect and structural engineer review the same set, instead of handing each file around to different vendors.

What gets checked first

We begin with the plot frontage, road width, setback needs for the specific plot, and the likely building type. A narrow frontage in Porur will need a different rhythm from a 40-foot front on a quieter lane. A house for a family with two cars also needs gate swing, turning room and rainwater path to be settled early, because you can't fix those after the shuttering is done.

We also check the practical materials. A boxy modern elevation in fibre-cement, texture paint and grooves behaves differently from one with natural stone bands, glass railings and aluminium louvers. Each choice changes cost, maintenance and heat gain. In our weather, a design that needs constant washing is not a good design.

1. Brief and plot study - We review your plan, frontage, road side, floor count and the look you want. This usually takes 1 to 2 working days after we receive the base drawing.
2. Concept elevation - We prepare the front massing, window alignment and major projection lines. This is the stage where shape and proportion are fixed.
3. 3D views and revisions - We turn the concept into views you can judge from the road and from the gate. One or two revision rounds are normally enough if the brief is clear.
4. Final drawing set - We issue the agreed elevation views and the related notes for the site team so the built work follows the same intent.

How to judge a designer before you pay

People usually ask for “best” elevation work, but what they really need is a design team that won't trap them with a nice image and a vague handoff. Ask for the drawing list, not just the final picture. Ask who checks the structural feasibility. Ask how many revisions are included and whether the person presenting the model also understands the actual RCC work.

• See the plan, front elevation and section together, not as separate promises.
• Confirm whether the design is being checked against the actual beam and slab positions.
• Ask for the material palette in writing: paint type, cladding, railing, sunshade, gate and compound wall finish.
• Check how revisions are handled. One free revision round is normal on a clear brief; endless changes are not.
• Make sure the team can explain what will happen at site if you choose a projection, a canopy or a feature wall.
• Reject any design that cannot be built within the structure you can afford.

Cost, approvals and what really affects the finish

For elevation and design work in Chennai, the price depends on the detail level, the number of views, whether structural coordination is included, and whether the same team is also handling the build. We do not quote total project cost here because that is decided only after the BOQ is prepared. For reference, interior works sit at ₹1,200 - ₹2,500 per sq ft, residential construction at ₹1,900 - ₹2,300 per sq ft for standard finishes, and premium work moves higher when the finishes get heavier. Those figures still change with soil, foundation type, number of floors, span, finish level and site access.

In Porur, the approval path depends on where the plot falls. The building licence may come through the Greater Chennai Corporation or the local municipality, while CMDA planning rules still matter across the Chennai Metropolitan Area. If the design is near airport influence or in a tighter road condition, height and service details may need another look. We confirm that for the exact plot before work starts.

How we work on these drawings

We keep the technical work in-house. Our architect, structural engineer and civil team review the same brief, and the site engineer stays close to the job once construction begins. Mr. D. Salamon Ashok Rajan, our Managing Director, personally reviews projects, because a front elevation only looks good when the structure, budget and buildability all agree.

If you want a 3D elevation for a new house in Porur, send the plot size and your rough plan. We can discuss the design direction, the likely material choices and what is realistic for the budget. You can call us on +91 97107 13838 or write to info@shalomconstruction.com. Our office is at No. 45, 2nd Main Road, Abirami Nagar, Koladi, Thiruverkadu, Chennai - 600077.

Frequently Asked Questions

When you are choosing 3D elevation designers in Porur, ask for something you can actually build. A neat picture is easy; a front that holds together on site, in heat, rain and budget, takes more care.
