House Plan Designers in Madipakkam
If you’re holding a plot in Madipakkam and trying to turn it into a workable house, the drawing has to do more than look neat. House plan designers in Madipakkam have to think about the plot line, road width, drainage, approval path and how the house will actually be built on site.
That is where most plans succeed or fail. A good plan should answer what fits, what needs approval, where the staircase goes, how light enters, and what the structure will cost before you start digging. We prepare drawings that can move from paper to foundation without surprises.
What Madipakkam asks from a house plan
Madipakkam is dense, built-up and close to Velachery, so the plot you have is usually not generous in every direction. Many sites are on streets where access is tight, neighbour walls are close, and material stacking space is small. That changes the design from the first sketch itself. You cannot draw a pleasant-looking plan and hope the site will somehow adjust later.
The other point is drainage. Parts of Madipakkam drain slowly in heavy rain, and that affects the finished level, plinth design, terrace runoff and where rainwater harvesting pits can sit. If you get the entry level wrong, you live with it for years. A plan that ignores that reality may still get printed, but it will not behave well after the first serious monsoon.
We also see a lot of plots here where families want one floor now and another later. That is common and sensible, but only if the column layout, staircase position and service shafts are fixed with the future floor in mind. Changing that later costs more than people expect.
Drawing the house, not just the room sizes
A proper house plan is a chain of decisions. We start with the plot dimensions, orientation, road side, setbacks that apply to that specific site, and how the owner wants to live. Then we shape the room sizes, circulation, ventilation and structure together. IS 456:2000 guides the RCC design, IS 875 handles loads, NBC 2016 guides planning and services, and IS 1893:2016 matters because Chennai sits in Seismic Zone III.
For Chennai projects, soil investigation comes before the foundation design. That is not a formality. In soft or water-retaining ground we may need raft or pile solutions with tie beams. On firmer ground, isolated or strip footings may be enough. The right answer comes from the bore test, not from a guess or from what worked on a neighbour’s plot two streets away.
What we prepare for you
For a house plan, the set usually includes concept sketches, dimensioned floor plans, elevation study, sections, structural drawings, and the service points that matter for execution. If the plot needs approval, we keep the drawings aligned with the authority’s process so you are not redrawing after submission. In many cases, the real value is not the sketch itself but the sequence behind it.
We also keep in mind how the house will be built. A plan with too many tight corners or awkward beam lines may look fancy on screen, but it slows shuttering, increases wastage and makes labour work harder. That shows up in cost. Clients notice it only when the quote comes back higher than they expected.
- Plot check and brief — We review the plot size, road side, existing levels and your room requirements. This usually takes 1 to 2 meetings.
- Concept plan — We place rooms, stair, parking and ventilation logic on paper. A first concept is usually ready in a few working days.
- Revisions — We adjust the plan after your comments. Most families need changes in circulation, kitchen position or room proportions.
- Structural coordination — We align the architecture with column spacing, beam lines and foundation logic before anything is issued for construction.
- Approval set — If the plot needs local approval, we prepare the drawing set and supporting documents in the format required by the authority.
How to choose a plan designer
If you are comparing firms, do not stop at the pretty elevation. Ask for the drawing list, the number of revisions, the engineering basis and the approval experience on a Chennai plot. A designer who can’t explain column positions or stair dimensions clearly is leaving the difficult part to the builder later. That later usually means extra cost.
Ask for the soil report approach, too. If someone talks confidently about footings without asking about the plot condition, they are guessing. Also ask whether the plan considers plumbing shafts, overhead tank position, sump access and rainwater harvesting. In Chennai, those are not side issues. Tamil Nadu has required rainwater harvesting since 2003, and you still need to leave room for it properly.
- Look for a plan that names the plot measurements and road side, not just a room list.
- Ask how many revisions are included before the drawing is final.
- Check whether structural drawings are coordinated with the architecture.
- See if the designer has handled CMDA-area approvals and the local licence route.
- Confirm that drainage, tank locations and RWH are shown on the drawing set.
- Reject plans that ignore future floors or force awkward column shifts.
Approvals, cost and the numbers that matter
For Madipakkam, the approval route depends on where the plot sits in the Chennai metropolitan area and which local body issues the building licence. CMDA is the planning authority, but the licence may come through the Greater Chennai Corporation or the relevant municipality or town panchayat depending on location. If the plot is near the airport side, height clearance can become part of the process. We confirm the actual route for your site before the drawing goes out.
House plan design itself is usually quoted as part of the overall project, not as a fixed public number, because the scope changes with the plot and the approval work. If you are also thinking about construction, our residential work in Chennai generally falls within the standard to mid-premium bands depending on finish and structure. The price moves with soil, foundation type, number of floors, span, finish level and site access, and the BOQ settles the real figure before any contract.
| Stage | Typical time | What you receive |
|---|---|---|
| Site study | 1 to 2 days | Plot review, measurement notes, brief on constraints |
| Concept design | 3 to 5 working days | Floor plan options and massing ideas |
| Revisions and coordination | 3 to 7 working days | Refined plan, stair and service coordination |
| Approval drawing set | Depends on the plot and authority | Submission-ready drawings and required documents |
How we work
We keep the technical work in-house. Our civil engineers, structural engineer and architect work from the same set of drawings, and Mr. D. Salamon Ashok Rajan reviews the project as well. A site engineer is on site every working day once construction starts. If you cannot visit often, we send weekly photo updates by WhatsApp. We also issue a detailed BOQ before contract signing, because a drawing without a quantity sheet leaves too much room for confusion. If you want to discuss your plot in Madipakkam, call +91 97107 13838 or write to info@shalomconstruction.com.
Frequently Asked Questions
If you want a plan that suits the plot instead of fighting it, we can help you sort the first drawing set, the approval route and the structural logic in one go. That saves time later, and usually saves a few arguments too.
